Description
YAMAHA MT-10/FZ-10 2022+
Optional Link Pipe/Collector (Titanium)
L-Y10SO19
-
- power
- +2.4 kWat 10700 rpm
-
- torque
- +4.8 Nmat 5700 rpm
-
- weight
- -7.3 kg
Designed as an optional accompaniment for
further exhaust-tuning capabilities for the Slip-On Line (Titanium) exhaust system, this
fully titanium link pipe removes the stock pre-muffler. Installed with the Slip-On Line (Titanium), it provides the bike with
power and torque gains of 1.4 kW (3.2 hp) at 10,700 rpm and 4.8 Nm at 5,700 rpm when measured on the Akrapovič dyno against a Yamaha MT-10 with a standard stock exhaust system. Along with a
deep racing sound, this item delivers a huge weight savings of 88.3% (7.3 kg) over the stock part. It has been developed for use on closed-course competition circuits, meaning that installation of this track-oriented system will invalidate the EC/ECE type-approval certificate of the Slip-On Line (Titanium).
ECU remapping is mandatory during installation to obtain optimal functionality. Exhaust can also be mounted on MT-10 SP and MT-10 Tourer Edition models. THIS PRODUCT DOES NOT MEET EMISSION COMPLIANCE REQUIREMENTS FOR STREET OR HIGHWAY USE.
TECHNICAL DATA
|
UNIT |
STOCK |
AKRAPOVIČ |
MAX GAIN |
max. power |
kW |
114.2 / 11500 rpm |
115.9 / 11500 rpm |
+ 2.4 / 10700 rpm |
|
HP (m) |
155.3 / 11500 rpm |
157.6 / 11500 rpm |
+ 3.2 / 10700 rpm |
|
HP (i) |
153.1 / 11500 rpm |
155.4 / 11500 rpm |
+ 3.2 / 10700 rpm |
max. torque |
Nm |
105.8 / 9300 rpm |
107.6 / 9450 rpm |
+ 4.8 / 5700 rpm |
|
lb-ft |
78.0 / 9300 rpm |
79.4 / 9450 rpm |
+ 3.5 / 5700 rpm |
weight |
kg |
8.2 |
1.0 |
– 7.3 |
|
lb |
18.1 |
2.1 |
– 16.0 |
|
% |
|
|
– 88.3 |
noise |
dB |
93.7 / 5600 rpm |
106.2 / 5500 rpm |
12.5 |
inst. time |
min |
|
90 |
|
ecu remapping |
Yes: For perfect performance, throttle response and durability, special developed mapping has to be used. |
